There are 16.000 holes with a diameter of Ø 1 mm on the front face of this panel. On the back surface, there are crosswise holes opened with a diameter of 5 Ø mm a intervals of 16mm x 16mm.
Perforation Ratio : %1
Frequency Type: It provides high acoustic absorption in low frequency sounds.
There are 32.000 holes with a diameter of Ø 1 mm on the front face of this panel. On the back surface, there are crosswise holes opened with a diameter of 5 Ø mm a intervals of 16mm x 16mm.
Perforation Ratio : %3
Frequency Type : It provides high acoustic absorption in low frequency sounds.
There are 64.000 holes with a diameter of Ø 1 mm on the front face of this panel. On the back surface, there are crosswise holes opened with a diameter of 5 Ø mm a intervals of 16mm x 16mm.
Perforation Ratio : %5
Frequency Type : It provides high acoustic absorption in low frequency sounds.
There are 128.000 holes with a diameter of Ø 1 mm on the front face of this panel. On the back surface, there are crosswise holes opened with a diameter of 5 Ø mm a intervals of 16mm x 16mm.
Perforation Ratio: %10
Frequency Type: It provides high acoustic absorption in low frequency sounds.
There are 128.000 holes with a diameter of Ø 0.5 mm on the front face of this panel. On the back surface, there are crosswise holes opened with a diameter of 5 Ø mm a intervals of 16mm x 16mm.
Perforation Ratio: %3
Frequency Type: It provides high acoustic absorption in low frequency sounds.
There are 294.000 holes with a diameter of Ø 0.5 mm on the front face of this panel. On the back surface, there are crosswise holes opened with a diameter of 5 Ø mm a intervals of 16mm x 16mm.
Perforation Ratio: %6
Frequency Type: It provides high acoustic absorption in low frequency sounds.
